Design and Manufacturing of Micro Drive System & Hinge mechanism Product—

Foldable Smartphone

Product Features

Slim, Reliable, Modular, and Seamless

Smooth · Durable · Quiet

Solution Details

Utilizing a modular design with a virtual axle directly driving the floating panel, the structure is compact and stable. Powder-formed ultra-high-strength steel and wear-resistant steel are employed to ensure hinge strength and longevity.

Products

SMSPD008008

Diameter（mm）:8

Length（mm）:11.3～16.7

Rated Voltage（VDC）:4.0

ZB15100

Size: 151.59*19.90*2.71mm
Torque: 0.80–1.60 kgf·cm
Angle: 0°–180°
Material: SUS420W+SUS304-WPB+SK5+SUS416+SUS420+SUS304
Lifespan: 200,000 Open-Close Cycles
