Metal Micro Drive System--Φ24MM

SMSMD024024

Diameter（mm）:24

Length（mm）:19.1～38.7

Rated Voltage（VDC）:12.0

Output Power（W）:0.1~4

Max Rated Torque （gf.cm):20000

Max Instant Torque（gf.cm）:60000

Customized consultation

Recommended Models

Drawings

Popular Products Applications

Recommended Models

Model	Typical Application Parameters								Max Rated Torque of Gear Box	Max Instant Torque of Gear Box	Gear Ratio	Gear Box Length
	Rated	At No Load		At Rated Load			Overall Length
	Voltage	Speed	Current	Speed	Current	Torque	Overall Length
	VDC	rpm	mA(MAX)	rpm	mA(MAX)	gf.cm	mN.m	mm	gf.cm	gf.cm		mm
SMSMD024024-4	12.0	1471	70	1250	215	101	9.9	49.6	20000	60000	4	19.1
SMSMD024024-6	12.0	980	70	833	215	151	14.8	49.6	20000	60000	6	19.1
SMSMD024024-16	12.0	368	75	313	215	339	33.2	55.5	20000	60000	16	24.7
SMSMD024024-24	12.0	245	75	208	215	508	49.8	55.5	20000	60000	24	24.7
SMSMD024024-36	12.0	163	75	139	215	762	74.7	55.5	20000	60000	36	24.7
SMSMD024024-64	12.0	92	75	78	220	1138	111.6	62.5	20000	60000	64	31.7
SMSMD024024-96	12.0	61	75	52	220	1561	153.0	62.5	20000	60000	96	31.7
SMSMD024024-144	12.0	41	75	35	220	2560	251.1	62.5	20000	60000	144	31.7
SMSMD024024-216	12.0	27	75	23	220	3841	376.7	62.5	20000	60000	216	31.7
SMSMD024024-256	12.0	23	80	20	220	3824	375.0	69.5	20000	60000	256	38.7
SMSMD024024-384	12.0	15	80	13	220	5735	562.5	69.5	20000	60000	384	38.7
SMSMD024024-576	12.0	10	80	9	220	8603	843.7	69.5	20000	60000	576	38.7
SMSMD024024-864	12.0	7	80	6	220	12905	1265.6	69.5	20000	60000	864	38.7
SMSMD024024-1296	12.0	5	80	4	220	19357	1898.4	69.5	20000	60000	1296	38.7

The specifications above are for reference only and can be adjusted according to customer requirements regarding product appearance and technical parameters.
